The Fire-Resistant Shutter Curtain is a high-performance fabric-based fire protection solution designed for use in fire-rated rolling shutters and fire compartmentation systems.
Manufactured from high-strength fiberglass fabric, it provides excellent resistance to flame, radiant heat, sparks, and molten metal splash during fire emergencies.
As a fiberglass fabric source manufacturer, RUISHUN supplies fire-resistant shutter curtain materials with stable quality, consistent thickness, and customizable fireproof coatings to meet different fire rating and installation requirements.
Excellent Fire Resistance
Made from non-combustible fiberglass fabric with high melting point
High Tensile Strength & Dimensional Stability
Maintains integrity during fire exposure and thermal shock
High Temperature Resistance
Continuous working temperature up to 550–600°C
(Higher with special coatings)
Fabric-Based & Lightweight
Easier installation compared with rigid fire shutter panels
Flexible Customization
Thickness, weight, coating type, width, and color available
Factory Direct Supply
Stable production, bulk orders, OEM & export-ready
Base Fabric: Woven Fiberglass Fabric
Optional Coatings:
Silicone Coated Fiberglass
Vermiculite Coated Fiberglass
Aluminum Foil Laminated Fiberglass
Reinforcement Options: Wire-insert / high-density weave
Fire-rated rolling shutter systems
Industrial fire curtains & compartmentation
Warehouses & logistics centers
Commercial buildings & shopping malls
Underground parking & metro stations
Factory fire separation zones
✅ Fiberglass Fabric Source Factory – full control of weaving & coating
✅ Stable Quality for Fire Protection Systems
✅ Customization for Fire Shutter Manufacturers
✅ Export Experience for Global Markets
✅ Consistent Supply & Competitive Factory Pricing
RUISHUN works closely with fire shutter system manufacturers, installers, and project contractors worldwide.
| Property | Value |
|---|---|
| Base Material | Fiberglass Fabric |
| Thickness | 0.6 – 1.5 mm (customizable) |
| Weight | 430 – 1200 g/m² |
| Continuous Temperature | 550–600°C |
| Short-Term Temperature | Up to 1000°C (with coating) |
| Flame Resistance | Non-combustible |
| Tensile Strength (Warp/Weft) | High (custom spec available) |
| Coating Options | Silicone / Vermiculite / Aluminum Foil |
| Width | Up to 3000 mm |
| Color | Natural / Gray / Silver / Custom |
Exact specifications can be customized based on fire rating and shutter system design.
A fire-resistant shutter curtain is typically made from high-strength fiberglass fabric, which is non-combustible and dimensionally stable. For enhanced fire and heat protection, it may also feature silicone, vermiculite, or aluminum foil coatings, providing superior resistance to flames, radiant heat, and sparks in industrial and commercial fire shutter systems.
Yes. Fiberglass fabric is widely used in fabric-based fire shutter curtains due to its non-combustible nature, excellent thermal stability, and high tensile strength. Coated or laminated fiberglass fabrics can meet strict fire protection standards and maintain structural integrity during fire exposure, making them ideal for rolling fire shutters and industrial fire curtains.
Standard fiberglass fabric can withstand continuous temperatures up to 550–600°C. With special fireproof coatings like silicone or vermiculite, resistance can reach higher short-term temperatures, making it suitable for high-temperature industrial applications and fire-rated rolling shutter systems.
Yes. Fire-resistant shutter curtains can be fully customized according to project requirements, including fabric thickness, weight, width, coating type, color, and reinforcement options. This allows manufacturers and contractors to design curtains for specific fire ratings, building codes, and industrial safety standards.
Fabric-based fire shutter curtains are widely used in industrial, commercial, and public building fire compartmentation systems. When properly installed and certified, they comply with fire safety regulations and standards for rolling fire shutters, fire curtains, and high-temperature protection.
Q6: What are the main applications of fire-resistant fiberglass shutter curtains?
These curtains are ideal for fire-rated rolling shutters, industrial fire curtains, commercial buildings, warehouses, logistics centers, underground parking, and fire compartmentation systems. They provide reliable fire protection while maintaining lightweight flexibility for easier installation and maintenance.
With proper storage and maintenance, fiberglass-based fire shutter curtains can have a long service life. Their durable non-combustible material and optional coatings ensure they remain effective under normal environmental conditions for many years.
Installation is typically performed by trained technicians or shutter system manufacturers. The curtains can be integrated into rolling shutter frames, fire curtain housings, or partition systems. Custom dimensions, coatings, and reinforcements are applied to meet specific fire rating requirements.
Yes. As a fiberglass fabric manufacturer, RUISHUN provides factory-direct supply, custom production, and technical support for industrial projects, OEM orders, and export markets worldwide.
